Cross Steering Rod for Husqvarna BD 62 Double Beam Screed

Standardowa 12-miesięczna Gwarancja Husqvarna

Firma Husqvarna zapewnia 12-miesięczną gwarancję na wszystkie swoje produkty. To standardowy okres ochrony, który daje pewność jakości i niezawodności każdej maszyny zakupionej od tego producenta.

Wybierając produkty Husqvarna, inwestujesz w sprzęt objęty roczną gwarancją, która obejmuje wszystkie elementy i podzespoły, gwarantując ich sprawne działanie przez cały rok.

Which machine does the Husqvarna BD 62 cross steering rod fit?

The cross steering rod is a Husqvarna catalogue item assigned to the BD 62 double beam vibratory screed, the profile with a 6.2 m working length. The BD range covers four lengths: 3.2 m, 4.2 m, 5.2 m and 6.2 m, and spare parts are matched to the profile model. Check which length your screed uses and state it in the enquiry before ordering.

What is the Husqvarna BD 62 double beam vibratory screed?

The Husqvarna BD 62 double beam vibratory screed is a 6.2 m working beam built from two parallel profiles that level and compact fresh concrete in a single pass. It carries no engine of its own, because vibration comes from a separate BE 20 electric drive unit powered from a 400 V supply. That working width suits industrial floors, warehouses, production halls and car parks.

Which drive unit does the Husqvarna BD 62 screed need?

BD range profiles work with the Husqvarna BE 20 electric drive unit running on 400 V. One drive unit serves all four profile lengths from 3.2 m to 6.2 m, so changing the working width means swapping the profile alone rather than the whole set. The same modular layout lets you replace single spare parts instead of the complete screed.

How does a double beam screed differ from a single beam one?

A double beam screed works with two beams at once: the first strikes off surplus mix, the second smooths the surface, which leaves a flatter floor after a single pass. Single beam designs use one beam and in the Husqvarna line-up cover the 1.8-4.2 m profiles of the BV 30 range. Double beam BD profiles reach 6.2 m and are built for large areas poured continuously.

Which other BD range spare parts are available?

Besides the cross steering rod, NORWIT.PL stocks the BD 62 pusher, the Husqvarna BD 32-62 skid set, the BD boom and the BD double profiles themselves in four lengths from 3.2 m to 6.2 m. Every item comes from the manufacturer catalogue, so it fits without modification. Parts for the single beam BV 30 screeds and for the BT 90 truss screed are listed separately.

How do I order a spare part for a Husqvarna vibratory screed?

Spare parts for Husqvarna BD range screeds are sourced to order. In your enquiry give the screed model together with the profile length, for example BD 62 with a 6.2 m profile, and the name of the part you need. We confirm availability and delivery time on that basis. You can place the order through the contact form or directly from this product page.
