Description
Nivel System SJJ-M10 MOTOR motorized laser tripod – automatic beam alignment
The Nivel System SJJ-M10 MOTOR is a motorized aluminium tripod for cross-line lasers with an auto-alignment function. Its motorized mast raises the laser up to 3.2 m (2.5 m tripod + 0.7 m extension) and folds down to just 1.1 m. From the Nivel System brand.
Auto-alignment and remote control
The mast shifts the beam vertically over 32 cm in 0.2 mm steps, and a radio remote controls the tripod from up to 50 m. With the optional CLS-10 sensor the tripod aligns the beam to the sensor centre automatically — the function works up to 20 m and supports all beam colours.
Rugged build for the field
A 5/8″ laser mount, cam-lever legs with a screw lock and universal feet (rubber indoors, spikes outdoors). IP56 protection, 5 kg load capacity, 6.5 kg weight. Powered by a CL 2600 Li-ion battery (2600 mAh, USB charging); carrying bag included.
Order the SJJ-M10 MOTOR tripod at NORWIT.PL
Go for fast, accurate beam setting. Check the adjustable tripods and the full range of Nivel System at NORWIT.PL.
Product Details
Indeks:
SJJ-M10 MOTOR
- Weight
- 6,5 kg
- Brand
- Nivel System
- Mounting (male thread)
- 5/8"
- Operating temperature range
- -20 °C - 50 °C
- Resistance class
- Ip56
- Remote control
- Radiowy, zasięg do 50 m
- Auto-fit function
- Tak — z czujnikiem CLS-10 (do 20 m)
- Maximum height
- 3,20 m
- Minimum height
- 1,10 m
Questions and answers
How does auto-alignment work on the SJJ-M10 MOTOR tripod?
The motorized mast automatically sets the laser beam to the centre point of the CLS-10 sensor. The function works up to 20 m and supports all beam colours of Nivel System cross-line lasers.
How high does the SJJ-M10 MOTOR raise the laser?
Maximum height is 3.2 m (2.5 m tripod + 0.7 m extension), and folded down it is just 1.1 m. The motorized mast shifts the beam vertically over 32 cm in 0.2 mm steps.
How is the SJJ-M10 MOTOR controlled?
The tripod is controlled wirelessly with a radio remote from up to 50 m — up/down adjustment is mechanical, without approaching the device.
Which sensor is needed for auto-alignment?
The optional CLS-10 sensor provides the auto-alignment function and communicates with the tripod by radio. Without the sensor the tripod works as a motorized mast controlled by the remote.
What power and protection does it have?
The tripod is powered by a CL 2600 Li-ion battery (2600 mAh, USB charging), and the IP56 rating allows work in tough conditions. Load capacity 5 kg, weight 6.5 kg, carrying bag included.
Which lasers fit the SJJ-M10 MOTOR?
The tripod is designed for cross-line lasers and has a 5/8" mount. Universal feet (rubber indoors, spikes outdoors) suit construction and finishing work.
